5
After successful coding, install the PIR detector. Please pay
attention to the installation height and detecting area. Make
sure the switch is powered on after adjusting angle and height.
2
After installation, please walking in the range of detecting,
if the siren rings out, the alarm is working.
3
Set the alarm panel to coding status (please refer to the alarm
panel manual), then trigger the detector by hand (or walking in
front of the detector) to make it send wireless signal to the
alarm panel for coding.
1
Test and Coding
110°
0m 3m 6m 9m
2m
Detection Range
Top view
Side view
0m
