Technical Data
Integrated Modules
Integrated Modules
5-3
#826498 - Revision B - November, 2016
Power Level Charts
The power level charts list the element information. Percentages, wattages, current, resistance, and temperatures
are approximate.
Level LEDs Displayed % of Power
1200 W
Element
700 W
Element
2 Zone
2200 W
Element
2 Zone
Operation Limit
0 0 0% 0.0 0.0 0.0
1 MLT/SIM 2% 24 Watts 14 Watts 44 Watts 8 Hours
2 2 5% 60 Watts 35 Watts 110 Watts 8 Hours
3 3 10% 120 Watts 70 Watts 220 Watts 6 Hours
4 4 17% 204 Watts 119 Watts 374 Watts 6 Hours
5 5 25% 300 Watts 175 Watts 550 Watts 6 Hours
6 6 35% 420 Watts 245 Watts 770 Watts 6 Hours
7 7 50% 600 Watts 350 Watts 1100 Watts 6 Hours
8 8 60% 720 Watts 420 Watts 1320 Watts 2 Hours
9 9 75% 900 Watts 525 Watts 1650 Watts 2 Hours
10 HI 100% 1200 Watts 700 Watts 2200 Watts 2 Hours
CE152TF/S” Electric Power Level
Level LEDs Displayed % of Power 1400 W Coil 2300 W Coil Operation Limit
0 0 0.00% 0.0 0.0
1 MLT/SIM 2.00% 28 Watts 46 Watts 8 Hours
2 2 5.50% 77 Watts 126.5 Watts 8 Hours
3 3 11.00% 154 Watts 253 Watts 6 Hours
4 4 16.50% 231 Watts 379.5 Watts 6 Hours
5 5 22.00% 308 Watts 506 Watts 6 Hours
6 6 26.50% 371 Watts 609.5 Watts 6 Hours
7 7 36.00% 504 Watts 828 Watts 6 Hours
8 8 50.00% 700 Watts 1150 Watts 2 Hours
9 9 75.00% 1050 Watts 1725 Watts 2 Hours
10 HI 100.00% 1400 Watts 2300 Watts 2 Hours
Boost Boost N/A N/A 3150 Watts 30 minutes
CI152TF/S Induction Power Level
