Integrated Modules
Integrated Modules
Technical Data
5-4
#826498 - Revision B - November, 2016
Level LEDs Displayed Temperature Operation Limit
0 0 0.0
1 LO 120°F None
2 1 130°F None
3 2 140°F None
4 3 150°F None
5 4 160°F None
6 5 170°F None
7 6 180°F None
8 7 190°F 12 Hours
9 8 200°F 12 Hours
10 HI 210°F 12 Hours
SM152TF/S Power Level
Level LEDs Displayed Temperature Operation Limit
0 0 0.0
1 LO 190°F 4 Hours
2 1 250°F 4 Hours
3 2 300°F 4 Hours
4 3 325°F 4 Hours
5 4 350°F 4 Hours
6 5 360°F 4 Hours
7 6 370°F 4 Hours
8 7 380°F 4 Hours
9 8 390°F 4 Hours
10 HI 400°F 4 Hours
FM152TF/S Power Level
