IN STA LL AT ION I N S T R U C T I O N S
EL ECT RI CA L R E Q U I R E M E N T S
ELECTRICAL SHOCK HAZARD—
Plug into a grounded 3-prong adapter.
Do not remove ground prong.
D
o not use an adapter.
Failure to follow these instructions can
result in electric shock, fire or death.
IMPORTANT NOTE:
Connection of this appli-
ance should be through a fused connection
unit or a suitable isolator, which complies with
national and local safety regulations. The
on/off switch should be easily accessible after
the appliance has been installed. If the switch
is not accessible after installation (depending
on country) an additional means of disconnec-
tion must be provided for all poles of the
power supply. When switched off there must
be an all pole contact gap of 3 mm in the
isolator switch. This 3 mm contact disconnect
gap must apply to any isolator switch, fuses
and/or relays according to EN60335.
R E C O M M E N D E D G R O U N D M E T H O D
IMPORTANT NOTE:
For your personal safety,
this cooktop must be grounded. This cooktop
is equipped with a 3-prong ground plug. To
minimize possible shock hazard, a 85C
minimum rated cord must be plugged into a
mating 3-prong ground-type outlet, grounded
in conformance with all local codes and ordi-
nances. If a mating outlet is not available, it is
the obligation of the customer to have a
properly grounded, 3-prong outlet installed by
a qualified electrician.
IMPORTANT NOTE:
If product is connected to
a GFCI protected outlet, nuisance tripping of
power supply may occur, resulting in loss of
product operation.
W I R I N G D I A G R A M
A wiring diagram covering the control circuit
for each Wolf gas cooktop model can be found
on page 17.
IMPORTANT NOTE:
If codes permit and a
separate ground wire is used, it is recom-
mended that a qualified electrician determine
that the ground path is adequate.
IMPORTANT NOTE:
Check with a qualified
electrician if you are not sure whether the
cooktop is properly grounded.
IMPORTANT NOTE:
Do not ground to a gas
pipe.
A 220-240 V AC, 50/60 Hz, fused electrical
supply is required. A time-delay fuse or circuit
breaker is recommended. It is recommended
that a separate circuit serving only this appli-
ance be provided.
Electronic ignition systems operate within
wide voltage limits, but proper ground and
polarity are necessary. In addition to checking
that the outlet provides 220-240 V AC power
and is correctly grounded, the outlet must be
checked by a qualified electrician to see if it is
wired with correct polarity. A wiring diagram is
provided in the literature package.
This appliance, when installed, must be electri-
cally grounded in accordance with local codes.
