13
Dimensions in parentheses are in
millimeters unless otherwise specified.
INSTALLATION INSTRUCTIONS
CABINET SUPPORTS
IMPORTANT NOTE:
When the warming
drawer is installed with a built-in oven,
a
dditional clearance between openings may be
required. Check that oven supports do not
obstruct the interior dimensions required for
t
he warming drawer.
T
he warming drawer with stainless steel
drawer front may be supported by either a
solid platform, 2" (51) x 2" (51) runners or 2"
(51) x 4" (102) runners. The platform or runners
must be level, rigidly mounted and flush with
the bottom edge of the opening. They must be
able to support 200 lbs (91 kg).
If an integrated drawer front is used, it must be
supported by a
5
/8" (16) solid platform. The
platform will need to be recessed and allow for
overlap of the warming drawer collar. Refer to
page 16 for additional details. The platform
must be level, rigidly mounted and must be
able to support 200 lbs (91 kg).
IMPORTANT NOTE:
Make sure that the
platform or runners are level. There is no way
to level the warming drawer once it has been
installed.
UNPACK THE WARMING DRAWER
Unpack the warming drawer on a flat surface.
Remove all packaging materials and tape from
i
nside the warming drawer and discard. Do not
discard the package containing the two wood
screws needed for installation.
