21
1
Dash camera
2
Connected to reversing light
3
Outside the car bracket
4
Inside the car bracket
・
Rear Camera Wiring Instructions
Note:
The rear camera has two wire routing options, both of which
conceal the wire along the edges of the door.
1. Connect the rear camera
cable to the mirror
Plug the rear camera cable into
the AV inteace of the unit.
To Next Page
