PACKAGE CONTENTS & HARDWARE LEGEND (Continued)
NOTE: Hardware parts (screws, nuts, washers) shown are actual size.
Unless otherwise marked, all parts are common to Models 6155 and 6156.
10
DESCRIPTION
Carriage bolt, black (M6x16)
(Model 6155 only)
QTY.
24
ITEM
AR
Toothed washer, black (M6)
(Model 6155 only)
24
Hex nut, black (M6)
(Model 6155 only)
24
Hex nut, black (M8) 1
Washer, black (M8) 2
AS
AT
AU
AV
AW
Wing nut, black (M8)
1
AX Hex head bolt, zinc
(M6x30)
1
AS
AT
AU
AV
AW
AX
AR
Cap nut, zinc (M6)
2AY
AY
AZ Pivot pin 1
AZ
To Next Page
