4 Base settings
Loosen the 2 screws to adjust the base to a 45° angle to the left or right.
The blade guide is adjusted with two screws to stabilise blade operation.
5 Sawing tips
Position the base over the uncovered area.
Move the saw forward with a little force.
6 Dust extraction
The jig saw is equipped with a dust extraction tube. The vacuum cleaner can be connected
to the tube at the rear of the jigsaw. If you require a special adapter, please contact the
manufacturer of your vacuum cleaner.
The emission values have been measured in accordance with the relevant standards.
Value of vibrations emitted
WARNING! Use hearing protection if the sound pressure exceeds 85 db(A).
TECHNICAL DATA
NOISE INFORMATION
Rated power
Electricity consumption
Depth of cut in wood
Depth of cut in steel
Mitre cuts
Sound pressure level LpA
Sound power level Lwa
Wood cutting
Steel cutting
230-240 V, 50 Hz
400 W
55 mm
6 mm
Max. 45° (left and right)
101.3 dB(A)
90.3 dB(A)
ah,B =10.359 m/s²
ah,M = 12.141 m/s²
K=3 dB(A)
K=3 dB(A)
K = 1.5 m/s²
K = 1.5 m/s²
