Parts 47
51861 (Rev. 6/16/2006)
BH1050 540 RPM HYDRAULIC PUMP
REF PART QTY DESCRIPTION
1 ----- † 1 Front seal
2 NSS 1 Retaining ring
3 ----- † 1 Rear seal
4 NSS 1 Mounting flange
5 ----- † 2 Outer O-Ring
6 ----- † 2 Nylon back-up strip
7 ----- † 2 O-Ring
8 NSS 4 Plate O-ring
9NSS1Key
10 NSS 2 Pressure plate
11 NSS 1 Idler gear
12 NSS 4 .438 Fastener
13 NSS 4 Dowel
14 NSS 1 Drive gear
15 NSS 1 Gear housing
16 NSS 1 Rear cover
17 NSS 8 .438 Washer
18 NSS 8 .438 Hex nut
19 ----- † 2 Stuffer strip
20 34365 1 Pump seal kit, Sundstrand (includes
items 1, 3, 5, 6, 7, and 19)
21 ----- - Hydraulic gear pump assembly,
Sundstrand
† Included in seal kit
NSS Not sold separately
REF PART QTY DESCRIPTION
