8
4. Components: function and handling
4.1. The woom bike and its components
1 Handlebar 6 Rims 11 Chain protector ring 16 Seatpost
2 Brake lever 7 Hub 12 Pedal crank 17 Seatpost clamp
3 Brake 8 Tires 13 Chain 18 Frame
4 Fork 9 Pedal 14 Derailleur 19 Headset clamp
5 Spokes 10 Inner bearing 15 Seat 20 Stem
1
10
20
9
12
19
13
7
11
14
2
4
3
18
6
6
3
15
5
16
17
8
8
Image: woom bike components
