13
Operating the Appliance
6 720 610 577 GB (03.02)
3.3 Switching on the Central Heating
B Turn the central heating temperature control to the desired
level:
– “Min” setting: 35˚C
– Low-temperature heating: setting “E” (approx. 75˚C)
– “Max” setting: 88˚C
When the burner is lit, the red indicator lamp is illuminated.
3.4 Controlling Central Heating
B Set the timer to the correct time.
B Set room thermostat to the desired room temperature.
B Set temperature driven control unit, if fitted. Refer to the
instructions with the control.
B Set the thermostatic radiator valves to the desired settings.
