OPERATION AND SERVICE INFORMATION
3-9
Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings
• accelerator pedal
• brake pedal
• park brake
•horn
• differential lock
KEY/LIGHT SWITCH
Located on the dash panel, this switch enables the basic electrical sys-
tem of the vehicle to be turned on and off by turning the key. To prevent
inadvertent operation of the vehicle when left unattended, the key
should be turned to the ‘OFF’ position and removed (Ref Fig. 9 on page
3-9).
If the vehicle is equipped with lights, the key switch has a position to
operate them, indicated by the light icon.
If the vehicle is equipped with factory installed cus-
tom accessories, some accessories remain opera-
tional with the key switch in the ‘OFF’ position.
DIRECTION SELECTOR
To reduce the possibility of
component damage, the vehicle
must be completely stopped before moving the
direction selector.
Located on the console between the seats, this lever permits the selec-
tion of either forward or reverse (Ref Fig. 10 on page 3-9). The vehicle
should be left in forward when unattended.
Fig. 9 Key/Light Switch, Low Oil Pressure Light and Fuel Gauge
ON
OFF
FUEL
F
E
Low Oil Pressure
Indicator Light
Key/Light Switch
Fuel
Gauge
Fig. 10 Console Controls
Parking
Brake
75694G01
Choke
Direction
Selector
Differential
Locked
Differential
Unlocked
Differential
Lock Lever
(Stop Vehicle
Before Moving
Lever)
