Hold the tool firmly.
Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
Wear ear protectors.
Check the impact socket carefully for wear, cracks
or damage before installation.
Keep hands away from rotating parts.
Do not touch the ratchet head, impact socket, bolt,
nut or the workpiece immediately after long time
operation. They may be extremely hot and could
burn your skin.
2. LAYOUT AND UNPACKING
2.1 Layout (Fig. 1)
1. Paddle switch
2. Lock switch
3. R/F toggle(R:reverse F:forward)
4. Battery indicator light
5. Battery pack x1 (W125101A)
Battery pack x2 (W125102A)
6. LED
7. Drive anvil
8. Charger
2.2 Items supplied
Please check that the article is complete as specified
in the scope of delivery. If parts are missing, please
contact our online service center.
Open the packaging and take out the equipment
with care.
Remove the packaging material and any packaging
and/or transportation braces (if available).
Check to see if all items are supplied.
Inspect the equipment and accessories for
transport damage.
If possible, please keep the packaging until the end
of the guarantee period
Danger!
The equipment and packaging material are not
toys. Do not let children play with plastic bags,
foils or small parts. There is a danger of swallow-
ing or suffocating!
3. PROPER USE
The tool is intended for fastening bolts and nuts.
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with EN 62841.
Vibration emission value a =2.258 m/s² K uncertainty
= 1.5 m/s²
Warning!
The specified vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equipment
is used and may exceed the specified value in
exceptional circumstances.
The specified vibration value can be used to compare
the equipment with other electric power tools.
The specified vibration value can be used for initial
assessment of a harmful effect.
Warning!
The vibration emission during actual use of the
power tool can differ from the declared total value
depending on the ways in which the tool is used.
6
LpA sound pressure level 80.5 dB(A)
KpA uncertainty 3 dB
L
WA sound power level 91.5 dB(A)
K
WA uncertainty 3 dB
GB
Charger
Input:100-240V~,
50/60Hz 0.8A,
Output:13.5VDC,2.0A
Battery capacity
2000mAh/pack
Charging time Approx 1 hour
No load speed 0 - 200 rpm
Drive anvil 9.5mm(0.37inch)
Battery voltage
Maximum 12V/Nominal 10.8V
Weight 1.3kg(45.86oz)
Maximum torque 55N.m(487.12in-lbs)
4. Technical Data
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 62841.
