Assembly
10
1. Take the product out of the packaging.
2. Check to make sure that all parts are included (see Fig. A).
3. Check whether any individual parts are damaged. If this is the case, do
not assemble or use the product. Contact the manufacturer via the service
address indicated on the warranty card.
Basic cleaning
1. Remove the packaging material and all plastic wrappings.
2. Clean all parts of the product before first use as described in the chapter
“Cleaning”.
Assembly
Begin the assembly of the product close to the intended use
location.
1. Attach the top post
2
to the bottom post
3
. Screw to secure (see Fig. B).
Repeat for the other top posts and bottom posts.
2. Snap the plastic sleeves
4
in pair to the groove at the desired height of
the bottom shelf on all four assembled posts (see Fig. C).
Make sure the arrow markings on the plastic sleeves are pointing upwards.
3. Slide a shelf
1
along the four assembled posts until it has a snug fit with
the sleeves. Push down firmly on the corners of the shelf to secure (see Fig. D).
4. Repeat steps 2 and 3 to assemble all shelves. Make sure all shelves are level.
The product is now assembled and you can adjust the post feet for your desired
height (see Fig. E). Check the tightness of all connections before using the
product.
Wall mounting
− In order to prevent overturning, this product must be used
with the wall attachment device provided.
− A Phillips screwdriver
8
and an electric drill
9
are
required for securing the product to the wall.
− Ensure that the position where the drill hole is to be made is
free from pipes and other obstructions.
− Make sure to use the appropriate hardware and tools based
on what type of wall you have. Consult your local hardware
store for advice on suitable fixings.
