Hands-Free Portable Workstation EN
5
1. FIXED JAW
2. LOCK/RELEASE SWITCH
3. FRONT LEG LOCKING LATCH
4. FOOT PEDAL LOCKING LATCH
5. FRONT LEG
6. FOOT PEDAL
7. FOOT PLATE
8. REAR LEG
9. REAR LEG LOCKING KNOB
10. MAIN BODY
11. MOVING JAW FACING (2 PIECES)
12. MOVING JAW
13. FIXED JAW FACING
Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Clamping range 0~34-1/2”
Max. Clamping force 1 Ton(1000kg)
Clamp method Foot step
Max. Load 440lbs
Footprint (standing) 37”x35”x34-1/2”
Footprint (folded) 30”x11-3/4”x13”
Clamp travel – foot pedal 1” per step
Construction Solid steel
Machine weight 35lbs
ACCESSORIES
WX060 WX060.1 WX060.2
Tool tray / 1 /
Only use the appropriate accessories intended for this tool. Accessory information can be found on the
product packaging, at a WORX dealer or on our website at www.worx.com.
