Battery charger EN
6
1. BATTERY PACK *
2. CHARGER
3. CHARGE INDICATOR LIGHT
* Not all the accessories illustrated or
described are included in standard delivery.
We recommend that you purchase your accessories
listed in the above list from the same store that
sold you the battery charger. Refer to the accessory
packaging for further details. Store personnel can
assist you and offer advice.
TECHNICAL DATA
Rated input voltage 100-240V~50/60Hz
Output voltage 20V
Charging current 2A
Rated Input power 40W
Charge battery Li-Ion
Number of cells 4/5/10
Charging time (approx.)
Battery pack -- 1.3Ah 42min
-- 1.5Ah 45min
-- 2.0Ah 58min
-- 3.0Ah 95min
-- 4.0Ah 125min
Protection class
/II
Machine weight 0.45kg
For the technical data of the types, the number of
cells and the rated capacity of the batteries that can
be charged, please refer the nameplate of the battery
pack supplied by WORX.
CHARGING PROCEDURE
NOTE: Before using the tool, read the
instruction book carefully.
CHARGING INSTRUCTIONS
1. CHARGING YOUR BATTERY PACK
The charger and battery pack are specifically
designed to work together so do not attempt
to use any other devices. Never insert or allow
metallic objects into your charger or battery pack
connections because an electrical failure and hazard
will occur.
2. BEFORE USING YOUR CORDLESS TOOL
Your battery pack is UNCHARGED and you must
charge once before use.
3. HOW TO CHARGE YOUR BATTERY
CHARGING PROCEDURE
1) Plug the charger into an appropriate outlet.
2) Slide the battery pack into the charger. The
LIGHT (3) will become green and flash to show
charging has started.
3) After charging approx 1-2 hours, the light will
stay green without flashing, which means the
battery is full, and charging is completed.
WARNING: When battery charge runs
out after continuous use or exposure
to direct sunlight or heat, allow time for the
battery to cool down before re-charging to
achieve the full charge.
CHARGING INDICATOR
This charger is designed to detect some problems
that can arise with battery packs. Indicator lights
indicate problems (see table below). If this occurs,
insert a new battery pack to determine if the charger
is OK. If the new battery charges correctly, then the
original pack is defective and should be returned
to a service center or recycling service center. If the
new battery pack displays the same problem as the
original Battery Pack, have the charger tested at an
authorized service center.
Light ON/ Flash Status
Red on
Defective Battery
Red flash
- - - - -
Battery Temperature
Protection
The temperature of
battery pack is less than
0
o
C or more than 45
o
C.
Green on
Fully Charged
Green flash
- - - - - - Charging
