7.5A Electric Blower EN
98
SAVE THESE INSTRUCTIONS
SERVICING OF DOUBLE-INSULATED
APPLIANCES
A double-insulated appliance is marked with one or
more of the following: The words “DOUBLE
INSULATION“ or “DOUBLE INSULATED“ or the
double insulation symbol (square within a
square).
In a double-insulated appliance, two systems of
insulation are provided instead of grounding.
No grounding means is provided on a double-
insulated appliance, nor should a means for
grounding be added to the appliance. Servicing a
double-insulated appliance requires extreme
care and knowledge of the system, and should be
done only by qualified service personnel.
Replacement parts for a double-insulated appliance
must be identical to the parts they replace.
SYMBOLS
To reduce the risk of injury, user must
read instruction manual
Wear eye protection
Wear ear protection
Warning
Double insulation
Before any work on the machine itself,
pull the power plug from the outlet.
Keep bystanders away
Warning of hazard
Do not use in the rain or leave
outdoors while it is raining.
1. HANDLE
2. ON/OFF SWITCH/2-SPEED SWITCH
3. LOWER BLOWER TUBE
4. UPPER BLOWER TUBE
5. TUBE RELEASE BUTTON
6. FAN HOUSING
7. MOTOR HOUSING
8. EXTENSION CORD RETAINER
9. POWER PLUG
* Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
Type WG519 (5-designation of machinery,
representative of Electric Blower Vacuum)
Rated Voltage 120V~60Hz
Rated power 7.5A
Speed control 2- Speed
Air speed
100mph(160km/h) - 120mph(193km/h)
Airflow
360cfm(10m
3
/min) -
450cfm(12.7m
3
/min)
Machine weight 6.4lbs(2.9kg)
Protection degree
/II
Only use the appropriate accessories intended for
this tool. Accessory information can be found on the
product packaging, at a WORX retailer or on our
website at www.worx.com .
