20V Cordless Brushless Paint Sprayer EN
Setting the volume
-Turn the volume knob on the trigger
clockwise to increase the volume.
-Turn the volume knob on the trigger
counter-clockwise to decrease the
volume.
See Fig.
D1
Adjusting the air flow
Turn the air flow control from 1-10
according to your work .
See Fig.
D2
Spray pattern adjustment
Adjusting spray shape
-Horizontal pattern (‘up and down’
spraying motion)
- Vertical pattern(‘side to side’spraying
motion)
See Fig. E
Adjusting spray width
-Wide pattern (for spraying large
surfaces)
-Narrow pattern(For spraying smaller
areas, corners and edges)
See Fig.F
OPERATION
Checking the battery charge
condition
NOTE: Fig. G1 only applies for the bat-
tery pack with battery indicator light.
See Fig.
G1
Charging the battery pack See Fig.G2
Installing the battery pack See Fig.G3
Press the trigger
USER TIPS
1. Position the tool 15-20cm from the
spray surface, depending upon the spray
pattern size desired .Spray parallel to
the surface with smooth passes at a
consistent speed.
2. Apply a thin layer of liquid on the first
pass and allow to dry before applying a
second, slightly heavier coat.
3. It is recommended to partially pull
trigger first in order to start the turbine
before a spray pass is made.
See Fig. H
****It is not necessary for most liquids when used
with the nozzle of larger diameter. For use with the
nozzle of smaller diameter , thinning may be needed
to acheive a finer finish.If thinning is necessary, use
the filling cup to adjust as you need(See Fig.A3).
