Worx WX027L User Manual

LED 4-in-1 Light EN
9
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction book carefully.
ACTION FIGURE
BEFORE OPERATION
Charging the battery pack See Fig. A
Installing/Removing the battery pack See Fig. B
OPERATION
Switch Button Functions
1st Flashlight
2nd Lantern
3rd Desk Lamp Hi
4th Desk Lamp Lo
5th SOS
6th (Press & Hold) OFF
FOUR FUNCTION MODES
1. FLASHLIGHT
- Press function switch button(5) the first time, the LED light is on. This tool is in down position.
WARNING! Do not direct the light beam into eyes.
See Fig. C
2. LANTERN
- Pull light stick(3) partly out of the handle. This tool is in middle position.
- Press function switch button(5) the second time, the light stick is on.
NOTE: If the light of lantern is too bright, push part of the light stick back into the handle.
WARNING! Return light stick into handle with caution so as not to pinch hand or fingers.
See Fig.
D1,D2
3.1 DESK LAMP HI
- Pull light stick (3) until the pivot joint(4) out of the handle. This tool is in top position.
- Rotate the pivot joint to desired position.
- Press function switch button(5) the third time, half side of light stick is on with high light.
NOTE: Adjust the pivoting head to desired position according to the working need. The max
angle of the pivoting head is±72°.
See Fig.
E1, E2, E3
3.2 DESK LAMP LO
- Press function switch button(5) the fourth time, half side of light stick is on with low light. This
tool is still in top position.
NOTE: Adjust the pivoting head to desired position according to the working need. The max
angle of the pivoting head is±72°.
See Fig.E4
NOTE: After adjusted pivoting head to the desired angle, the light stick itself can still rotate.
The fine-tuning angle of the light stick (3) is±45°.
See Fig.E5
WARNING! Adjust the pivoting head carefully so as not to pinch hand or fingers.
4. SOS
- Back the pivot joint(4) into the handle, keep the light stick (3) on the outside. This tool is in
middle position.
- Press function switch button(5) the fifth time, the light stick is in SOS mode.
WARNING! Return light stick into handle with caution so as not to pinch hand or fingers.
See Fig.F

Worx WX027L Specifications

General

Brand	Worx
Model	WX027L
Category	Flashlight
Language	English
