SUGGESTED BATTERIES AND CHARGERS
Category Model Capacity
20V Battery WA3669 2.0 Ah
20V Charger WA3742 0.4 A
We recommend that you purchase your accessories from the same store that
sold you the tool. Refer to the accessory packaging for further details. Store
personnel can assist you and offer advice.
4. OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction book carefully.
INTENDED USE
The tool can be used for bonding wood, leather, plastics ,papers and other
materials.
OPERATION
ACTION FIGURE
Inserting or removing the battery pack See Fig. A
Charging the battery pack See Fig. B
Insert the glue stick into the glue stick hole See Fig. C
Press the ON/OFF switch for 3 seconds.
The heat indicator light will be red as it heats and will turn green
when it is ready to use.
See Fig. D
Press the switch trigger for gluing
NOTE: It is recommended to apply the glue on large surfaces
or long work pieces in the form of points. On exible materials,
apply in lines.
WARNING: Do not allow the hot glue or the nozzle tip
to come into contact with persons or animals.If hot
glue contacts with the skin, do not try to remove the glue
from the skin,but put the affected area immediately under a
stream of cold water for several minutes.
See Fig. E
