TECHNICAL DATA
NOISE INFORMATION
Model no. WX365 WX365.1
WX369 WX369.1
WX369.2
WX376 WX376.1
WX376.2
Voltage 14.4V 18V 24V
No load speed 0-350/ 0-1300/min
No load impact frequency 0-5600/ 0-20800/min
Number of clutch position 20+1+1
Max torque 40N.m 50N.m 60N.m
Chuck capacity 13mm 13mm 13mm
Max. drilling
capacity
Steel 13mm 13mm 13mm
Wood 30mm 38mm 40mm
Concrete 13mm 16mm 16mm
Machine weight 2.3kg 2.4kg 2.95kg
Model no. WX153 WX158 WX165
Voltage 12V 14.4V 18V
No load speed 0-350 / 0-1300/min
Number of clutch position 23+1
Max torque 25N.m 30N.m 50N.m
Chuck capacity 10mm 10mm 13mm
Max. drilling
capacity
Steel 10mm 10mm 13mm
Wood 25mm 28mm 35mm
Machine weight 1.8kg 1.95kg 2.3kg
A weighted sound pressure 89.6dB(A)
A weighted sound power 100.6dB(A)
K
PA
&K
WA
3.0dB(A)
Wear ear protection when sound pressure is over 85dB(A)
