Lithium-Ion Cordless Drill Driver EN
98
1. CHUCK
2. TORQUE ADJUSTMENT RING
3. TWO-SPEED GEAR CONTROL
4. FORWARD/REVERSE ROTATION CONTROL
5. SOFT GRIP HANDLE
6. BATTERY PACK
7. BATTERY PACK RELEASE BUTTON
8. LED LIGHT
9. ON/OFF SWITCH
* Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Type: WX183 WX183.1 WX183.2 WX183.9 (1-designation of machinery, representative of drill)
WX183 WX183.1 WX183.2 WX183.9
Rated voltage 20V Max**
No load speed 0-500 / 0-1700 /min
Number of clutch position 18+1
Max torque 50N.m
Chuck capacity 13mm
Max. drilling capacity
Steel 13mm
Wood 35mm
Machine weight 1.66kg 1.29kg
**Voltage measured without workload. Initial battery voltage reaches Maximum of 20volts. Nominal voltage is
18volts.
NOISE INFORMATION
A weighted sound pressure L
pA
: 73,8dB(A)
A weighted sound power L
wA
: 84,8dB(A)
K
pA
&K
wA
3.0dB(A)
Wear ear protection when sound pressure is over 80dB(A)
