Worx WX317.2 Instruction Manual

1110
Impact drill EN
1110
ENVIRONMENTAL
PROTECTION
Waste electrical products must not be
disposed of with household waste.
Please recycle where facilities exist.
Check with your local authorities or retailer for
recycling advice.
PLUG REPLACEMENT
(ONLY FOR REWIRABLE
PLUG OF UK & IRELAND)
If you need to replace the fitted plug then
follow the instructions below.
IMPORTANT
The wires in the mains lead are colored in
accordance with the following code:
Blue = Neutral
Brown = Live
As the colors of the wires in the mains lead of
this appliance may not correspond with the
colored markings identifying the terminals
in your plug, proceed as follows. The wire
which is colored blue must be connected to
the terminal which is marked with N. The wire
which is colored brown must be connected to
the terminal which is marked with L.
WARNING: Never connect live or
neutral wires to the earth terminal of the
plug. Only fit an approved 13ABS1363/A plug
and the correct rated fuse.
NOTE: If a moulded plug is fitted and has to
be removed take great care in disposing of the
plug and severed cable, it must be destroyed
to prevent engaging into a socket.
Connect
Blue to N
(neutral)
Outer sleeve
firmly clamped
Cable grip
Brown L (live)
13 Amp fuse approved
to BS1362
DECLARATION OF
CONFORMITY
We,
Positec Germany GmbH
Grüner Weg 10, 50825 Cologne, Germany
Declare that the product,
Description WORX Impact Drill
Type WX317 WX317.2 WX318
(300-329-designation of machinery,
representative of Impact Drill)
Function Boring holes in various
materials
Complies with the following Directives,
2006/42/EC
2011/65/EU
2014/30/EU
Standards conform to
EN 60745-1
EN 60745-2-1
EN 55014-1
EN 55014-2
EN 61000-3-2
EN 61000-3-3
The person authorized to compile the techni-
cal file,
Name Marcel Filz
Address Positec Germany GmbH Grüner
Weg 10, 50825 Cologne, Germany
2018/05/04
Allen Ding
Deputy Chief Engineer Testing & Certification
Positec Technology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China

Worx WX317.2 Specifications

General

Drilling	Yes
Chuck type	-
Product color	Black, Orange
Input power	600 W
Power source	AC
AC input voltage	230-240 V
AC input frequency	50 Hz
Impact rate	48000 bpm
Rated speed (max)	3000 RPM
Drilling diameter in wood (max)	25 mm
Drilling diameter in concrete (max)	13 mm

Weight and Dimensions

Weight	2100 g
