Worx WX317 Original Instructions

Impact drill EN
7
6
1. KEYLESS CHUCK
2. DEPTH GAUGE
3. DRILL/ HAMMER DRILL FUNCTION SELECTOR
4. SWITCH LOCK ON BUTTON
5. ON/OFF SWITCH
6. VARIABLE SPEED CONTROL
7. FORWARD AND REVERSE ROTATION CONTROL LEVER
8. AUXILIARY HANDLE
Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Type WX317 WX318 (300-329-designation of machinery, representative of Impact Drill)
WX317 WX318
Voltage 230-240V~50Hz
Power input 600W 810W
No load speed 0-3000/min
Impact rate 0-48000/min
Chuck capacity 13mm
Drilling capacity
Masonry 13mm 16 mm
Wood 25mm 32 mm
Steel 13mm 13 mm
Protection class
/II
Machine weight 2.1kg 2.42kg
NOISE/VIBRATION INFORMATION
WX317 WX318
A weighted sound pressure L
pA
: 99dB(A) L
pA
: 93,5dB(A)
A weighted sound power L
wA
: 110dB(A) L
wA
: 104,5dB(A)
K
pA
& K
wA
3.0dB(A)
Wear ear protection when sound pressure is over 80dB(A)

Worx WX317 Specifications

General

Input power	600 W
Power source	AC
AC input voltage	230-240 V
AC input frequency	50 Hz
Impact rate	48000 bpm
Rated speed (max)	3000 RPM
Drilling diameter in wood (max)	25 mm
Drilling diameter in concrete (max)	13 mm
Carrying case	Yes
Product color	Black, Orange

Weight and Dimensions

Weight	2100 g
