Worx WX352.9 User Manual

10
20V Cordless Impact Drill EN
Hammer drilling
Screwdriving
Drilling
Wood
Metal
Brick
High speed
Low speed
2.COMPONENT LIST
1. CHUCK
2. TORQUE ADJUSTMENT RING
3. TWOSPEED GEAR CONTROL
4. FORWARDREVERSE ROTATION CONTROL
5. SOFT GRIP HANDLE
6. BATTERY PACK 
7. BELT HOOK
8. BATTERY PACK RELEASE BUTTON 
9. LED LIGHT
10. ONOFF SWITCH
11. BIT CLIP
12. BATTERY CAPACITY INDICATOR 
* Not all the accessories illustrated or described
are included in standard delivery.
3.TECHNICAL DATA
Type WX352 WX352.X (3 - designation of
machinery, representative of Drill)
WX352 WX352.X**
Charger voltage 100-240V~50/60Hz
Rated voltage 20 V Max***
No-load speed 0-450/0-2000 RPM
Impact rate 0-32000 BPM
Number of clutch
position
22+1+1
Max torque 60 Nm
Chuck capacity 13 mm
Max.
drilling
capacity
Steel 13 mm
Wood 40 mm
Brickwork 12 mm
Concrete 12 mm
Machine weight (Bare
tool)
1.1 kg
**X=1-999, A-Z, M1-M9 there are only used for different
customers, there are no safe relevant changes
between these models
***Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal voltage
is 18 volts.
NOISE INFORMATION
A weighted sound pressure L
pA
: 87.9 dB(A)
A weighted sound power L
wA
: 98.9 dB(A)
K
PA
& K
WA
5.0 dB(A)
Wear ear protection.
