1. CHUCK
2. TORQUE ADJUSTMENT RING
3. TWO-SPEED GEAR CONTROL
4. FORWARD/REVERSE ROTATION CONTROL
5. SOFT GRIP HANDLE
6. BATTERY PACK *
7. BATTERY PACK RELEASE BUTTON
8. SIGHT LIGHT
9. ON/OFF SWITCH
* Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
WX372 WX372.1 WX372.2
WX372.3 WX372.4 WX372.5
WX372.8 WX372.10
WX372.7 WX372.9
Rated voltage 20V Max**
No-load speed 0-550 / 0-1800/min
Impact rate 0-8800 / 0-28800/min
Number of clutch position 22+1+1
Max torque 50N.m
Chuck capacity 13mm
Max. drilling
capacity
Steel 13mm
Wood 40mm
Brickwork 16mm
Concrete 13mm
Machine weight 1.65kg 1.98kg 1.29kg
**Voltage measured without workload. Initial battery voltage reaches maximum of 20 volts.
Nominal voltage is 18 volts.
