Cordless Hammer Drill
WX386 WX386.1 WX386.2 WX386.4 WX386.9
the Forward and Reverse Switch putting it into the
required rotation position. Push the trigger and the
drill will start to rotate (See Fig. C1, C2, C3)
2. THE DRILL STOPS BEFORE THE SCREW IS
COMPLETELY TIGHTENED. WHY?
Verify the torque position of the Torque Adjustment
Ring, you can find the Torque Adjustment Ring
between the Chuck and the drill body. Position
1 is the lowest torque (screw driving force) and
position 18 is the highest torque (screw driving
force). Position
is for drill operation. Position
is for hammer drill operation. Regulate the Torque
Adjustment Ring to a higher position to reach the
best result. (See Fig. E1, E2, E3)
3. I CAN NOT FIT THE BATTERY PACK INTO
THE BATTERY CHARGER. WHY?
The battery pack can be inserted into the charger
only in one direction. Turn the battery pack around
until it can be inserted into the slot. The charger LED
indicator should turn on when the battery pack is
charging.
4. REASONS FOR DIFFERENT BATTERY PACK
WORKING TIMES
Charging time problems, as above, and having not
used a Battery Pack for a prolonged time will reduce
the Battery Pack working time. This can be corrected
after several charge and discharge operations by
charging & working with your drill. Heavy working
conditions such as large screws into hard wood will
use up the Battery Pack energy faster than lighter
working conditions. Do not re-charge your Battery
Pack below 0
o
C and above 45
o
C as this will affect
performance.
MAINTENANCE
Remove the Battery Pack from the tool before
carrying out any adjustment, servicing or
maintenance.
Your power tool requires no additional lubrication
or maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to
clean your power tool. Wipe clean with a dry cloth.
Always store your power tool in a dry place. Keep
the motor ventilation slots clean. Keep all working
controls free of dust. Occasionally you may see
sparks through the ventilation slots. This is normal
and will not damage your power tool.
ENVIRONMENTAL
PROTECTION
Waste electrical products must not be disposed
of with household waste. Please recycle where
facilities exist. Check with your local authorities
or retailer for recycling advice.
DECLARATION OF
CONFORMITY
We,
Positec Power Tools (Europe)Ltd
PO Box 6242, Newbury, RG14 9LT, UK
Declare that the product,
Description WORX Cordless Hammer Drill
Type WX386 WX386.1 WX386.2 WX386.9
(3-designation of machinery, representative of
Hammer drill)
Function Hammering various materials
Complies with the following Directives,
2006/42/EC
2011/65/EU
2014/30/EU
Standards conform to
EN 55014-1
EN 55014-2
EN 60745-1
EN 60745-2-1
EN 60745-2-2
The person authorized to compile the technical file,
Name Jim Kirkwood
Address Positec Power Tools (Europe) Ltd, PO
Box 6242, Newbury, RG14 9LT, UK
2018/03/30
Allen Ding
Deputy Chief Engineer Testing & Certification
Positec Technology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China
