10
Lithium-Ion cordless
hammer drill
WX386 WX386.1
WX386.2 WX386.9
ACCESSORIES
WX386 WX386.1 WX386.2 WX386.9
Charger 1 1 1 /
Battery
pack
2 2 1 /
Double
Ended
Bit (PH2/
SL5.5)
1 / 1 1
158pcs
acces-
sories
/ 1 / /
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store
personnel can assist you and offer advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for driving in and
loosening screws as well as for drilling in wood,
metal and plastic.
ASSEMBLY AND OPERATION
ACTION FIGURE
BEFORE OPERATION
Removing the battery pack
See Fig. A1
Charging the battery pack See Fig. A2
Installing the battery pack See Fig. A3
ASSEMBLY
CHUCK ADJUSTMENT
WARNING: Always lock off trigger switch
and disconnect tool from power source when
changing accessories. Always ensure the bit is secure
before starting the tool. Damage to the Chuck or a
loose bit may cause possible personal injury.
--Removing the bits See Fig. B1
--Inserting the bits See Fig. B2
OPERATION
FORWARD/REVERSE
ROTATION CONTROL
WARNING: Never change
the direction of rotation
when the chuck is rotating, wait
until it has stopped!
See Fig.C1,
C2, C3
TWO-SPEED GEAR CONTROL
See Fig. D
TORQUE ADJUSTMENT
SCREWDRIVING, DRILLING,
HAMMER DRILLING
See Fig. E1,
E2, E3
OPERATING THE ON/OFF
SWITCH
WARNING: Do not
operate for long periods at
low speed because excess heat
will be produced internally.
See Fig. F
LED LIGHT INDICATOR (See Fig. F)
To turn on the light, press the on/off switch and make
sure the forward/reverse rotation control is on right/
left position. When you release the on/off switch, the
light will be off.
LED lighting increases visibility-great for dark or
enclosed area. LED is also a battery capacity indicator.
It will flash when power gets low.
The tool and battery pack are equipped with a
protection system. When the LED Light is quickly
flashing and turn off, the system will automatically
cut off power to the tool to extend battery life. The
tool will automatically stop during operation if the
tool and/or battery pack are placed under one of the
following conditions:
• Overloaded: The tool is operated in a manner that
causes it to draw an abnormally high current. In this
situation, release the Trigger Switch on the tool and
stop the application that caused the tool to become
overloaded. Then pull the Trigger Switch again to
restart.
• Overheated: Under the condition above, if the
tool does not start, the Tool and Battery Pack are
overheated. In this situation, let the Tool and Battery
Pack cool before pulling the Trigger Switch again.
• Low battery voltage: The remaining Battery
capacity is too low and the tool will not operate. In
this situation, remove and recharge the Battery Pack.
PROBLEM SOLUTION
1. WHY DOES THE DRILL NOT TURN ON WHEN
YOU PRESS THE SWITCH?
The Forward and Reverse Switch, which is on top of
the trigger, is positioned in the lock function. Unlock
the Forward and Reverse Switch putting it into the
required rotation position. Push the trigger and the
drill will start to rotate (See Fig. C1, C2, C3)
