WRC GT4-2 - Foglio1; Vista del disegno1; Vista del disegno2; Vista del disegno3

100802-L
95014
O-ring 6x2
100809
100805
100810
100811
100815
90024
8x16x5
100812
DIFFERENTIAL OIL :
Front : 1000000 cst
Weight : 3 g
97028
Ø2.5x11.8
Rounded Head Pin
100812
90024
8x16x5
100813-L
95014
O-ring 6x2
100809
100805
97028
Ø2.5x11.8
Rounded Head Pin
100804-05
92006
M3 x16
OPTIONAL
100804-01 (0.1mm)
100804-02 (0.2mm)
Fill the differential up to the top of the pin.
DO NOT fill the diff. to the top of the housing.
Front Diff. Gear
3
BAG 1
