WRC SBXE-1 - Foglio1; Vista del disegno8; Vista del disegno13; Vista in sezione A-A

92008
M3 x20
91011
M3x40
100506 F-F
100302-S (Soft)
100507 F-R
97024
Ø4x65
100512
100512
Lower Arm Position
Lower Arm Position
98019
M5x8
100452
ADJUST THE PLAY
WITH THE SHIMS
100452
AA
1
OPTIONAL
100302-M (Medium)
100302-H (Hard)
SCREW POSITION
Front Suspension
8
BAG 6
