Wright Manufacturing Sentar 31423 - Sentar Rear Discharge Assembly

REF. # DESCRIPTION PART #
1 CUTTER DECK W/ ISOL CAPS, 61"RD 93450020
1A CUTTER DECK W/ ISOL CAPS, 52"RD 93440031
2 BAFFLE, RD PIVOTING DEFLECTOR 93490006
3 RUBBER DEFLECTOR CAP STRIP,R, 52"RD 93440032
3A RUBBER DEFLECTOR CAP STRIP,R, 61"RD 93450021
4 RUBBER DEFLECTOR CAP STRIP,L, 52"RD 93440033
4A RUBBER DEFLECTOR CAP STRIP,L, 61"RD 93450022
5 BAFFLE, 52" RD RUBBER DEFLECTOR 76440001
5A BAFFLE, 61" RD RUBBER DEFLECTOR 76450001
6 LOCK PLATE, RD PIVOTING BAFFLE 93410093
7 BAFFLE, RD COCKPIT SIDE (SMALL) 93490008
8 BAFFLE, RD COCKPIT SIDE 93490007
9 FOOT PLATE PIVOT, ZINC PLATE 96410002
10 BOLT, HEX 3/8-16 X 2 Z5 11990005
11 BOLT, FLANGE 5/16 -18 X 3/4 Z5 11990012
12 NUT, LOCK FLANGE 3/8-16 Z 12990008
13 NUT, LOCK FLANGE 5/16-18 Z 12990007
14 NUT, TOPLOCK 5/16-18Z 12990039
15 BOLT, CARRIAGE 5/16-18 X 1 Z5 11990060
REAR DISCHARGE - UNIQUE COMPONENTS
© 2006 Wright Manufacturing, Inc. All rights reserved.
