REF. # DESCRIPTION PART #
1 OBTAIN FROM AUTHORIZED KAWASAKI DEALER 51410014
1A OBTAIN FROM AUTHORIZED KAWASAKI DEALER 51410010
1B OBTAIN FROM AUTHORIZED KAWASAKI DEALER 51410029
1C OBTAIN FROM AUTHORIZED KOHLER DEALER 51410013
2 HYDRO PUMP, W/RTN RIGHT 31490009
3 HYDRO PUMP, W/RTN LEFT 31490010
4 CS PUMP LEVER 93410140
5 CS PUMP LEVER 93410140
6 BOLT, CARRIAGE 7/16-14 X 1 1/4 Z5 11990081
7 BOLT, FLANGE 5/16 -18 X 3/4 Z5 11990012
8 WASHER, FLAT USS 5/16 z 13990010
9 NUT, LOCK FLANGE 5/16-18 Z 12990007
10 SCREW, TRUSS HD PH 1/4-20 X 1/2 SS 11990063
11 OIL COOLER COVER WELDMENT 91410019
12 NUT, U 1/4-20 12990012
13 OIL COOLER - STACKED PLATE 36470001
14 OIL COOLER CRADLE WELDMENT 91410018
15 MUFFLER GUARD, SENTAR/ KAW 91410012
15A MUFFLER GUARD, SENTAR/KOHLER 91410016
16 MUFFLER, SPECIAL KAW SENTAR 51410011
16A OBTAIN FROM AUTHORIZED KOHLER DEALER N/A
17 BRACKET, MUFFLER, LEFT SIDE 23 HP KAW 51410027
17A BRACKET, MUFFLER, RIGHT SIDE 23 HP KAW 51410028
18 OBTAIN FROM AUTHORIZED KAWASAKI DEALER N/A
19 CAP, VINYL 3/8 X 1 17460002
20 SPRING, TORSION 16410003
21 NUT, JAM 1/4-20 Z 12990042
22 O-RING, FOR KAWASAKI OIL DRAIN ADAPT 35410024
23 OIL DRAIN VALVE ADAPTER 35410018
24 OIL DRAIN VALVE 36410003
25 FITTING, MALE BARB 1/2 - 90 36410005
26 TUBE, OIL DRAIN 81410017
27 BOLT, HEX 5/16-24 X 1 1/2 Z5 11990009
28 NUT, LOCK FLANGE 5/16-24 Z 12990011
29 FITTING, MALE BARB 1/2 STRT 36410004
30 NUT, NYLOCK 5/16-18 Z 12990021
31 CLAMP, MUFFLER, 23HP KAW 51410015
31A CLAMP,MUFFLER, KOHLER 51410025
32 S-PIPE, MUFFLER, KAW 51410012
32A S-PIPE, MUFFLER, KOHLER 23 HP 51410024
33 MACH BUSH, 1/2 ID X 7/8 OD X 18 GA 13990015
34 NUT, HEX M8-1.25Z 12990041
35 HOSE CLAMP, 1/4 43410001
36 CLIP, HALF 5/8 15990002
37 BOLT, HEX 1/4-20 X 5/8 Z5 11990001
38 BOLT, HCS, 1/2-20X3.5 Z 11990089
39 HOSE, 1/4 FUEL 42420001
40 ENGINE DECK WELDMENT 93410214
41 NUT, NYLOCK 1/4-20 Z 12990019
42 NUT, LOCK FLANGE 7/16-14 Z 12990009
43 VALVE, FUEL 3-WAY 41410006
44 BOLT, HEX 3/8-16 X 2 Z5 11990005
45 HYDRAULIC PUMP BELT 71460064
46 PULLEY, SINGLE GRV 6 OD-A/B 71460053
47 PULLEY, SMALL IDLER, DECK 71460009
48 MACHINE KEY 1/4 X 1/4 X 1 15990003
49 PULLEY, 5-1/4" OD X A/B GRV X 1" ENG, WS 71410012
50 BUSHING SPLIT TAPERED X 17MM 71460042
51 MACHINE KEY 5MM X 5MM X 25MM 15990004
52 BOLT, HEX 1/4-20 X 7/8 GR8 PL 11990082
53 CLUTCH / BRAKE LARGE 71410013
54 SPACER, FOR CLUTCH 71410007
55 WASHER, LOCK 7/16 Z 13990014
56 BOLT, HEX 7/16-20 X 2 3/4 Z5 11990010
57 IDLER ARM ASSEMBLY, RIGHT, 7" 98490008
58 NUT, TOPLOCK 3/8-16 12990031
59 SPRING, 2.5" DECK IDLER SPRING 16460009
60 BEARING, BALL, FOR IDLER ARM 77410010
61 WASHER, FENDER 5/16 X 1 1/4 Z 13990032
62 NUT, NYLOCK 1/2-20 Z 12990038
63 IDLER ARM WASHER 93490009
64 SCREW, ROUND PHLP 1/4-20 X 2 Z 11990025
65 CIS BEARING BUSHING 25410003
66 ONE-PIECE ELECTRIC HARNESS W/ TIME DELAY 53490035
66A LOWER HARNESS-REPLACE W/ 53490035 & 5241007 N/A
67 HARNESS, ENGINE KAW 17 HP R/E & 23 53490017
68 SOLENOID 53490009
69 CABLE, BATTERY, RED 38" W/ LUG INSUL. 53490010
70 CABLE, BATTERY, RED 3 1/2" 53490012
71 CABLE, BATTERY, BLACK 18 1/2" 53490011
72 WIRE, GROUNDING 53490007
73 WASHER, LOCK 1/4 Z 13990020
74 FUEL FILTER 34490003
75 WATER RESISTANT RELAY 53490019
76 BOLT, FLANGE 5/16 -18 X 1 11990013
77 SPACER, 5/8 X 1/8 X 3/8 93410163
78 BOLT-ON CLUTCH STOP 93410207
ENGINE DECK COMPONENTS
© 2006 Wright Manufacturing, Inc. All rights reserved.
