Installation Instructions
Basin assembly – Diamond Base
Preparing Drain Pipe Assembly - Place threaded cap portion of the drain coupler onto the telescopic drain pipe, apply PVC Glue to
the outside of the pipe and inside edge of flange(see picture). Please allow glue to fully set prior to use. (See directions on glue bottle)
Mounting the brackets - The shorter flanged motor bracket is to be mounted in the center of the spa chair using the 3
rd
and 5
th
holes from the motor bracket (see picture) using the two 1” bolts. The taller flanged drain pipe bracket is to be mounted to the left of
the motor bracket using the same 3
rd
and 5
th
holes also with the two 1” bolts.
