Technical data SenTix
®
4
ba75737e02 06/2013
Shaft dimensions, shaft material, electrical connection
* Coaxial plug according to DIN 19262
** Stage geometry
*** Measured from upper level of built-in grinding (standard grinding NS 7,5)
**** Connection cable not included in the scope of delivery of the combination
electrode (see W
EAR PARTS AND ACCESSORIES)
WTW model Shaft Electrical connection
Length
[mm]
Ø [mm] Material Combination
electrode
connection
Meter con-
nection
Cable
length
SenTix
®
51 120 12 Polyamide Fixed cable DIN*+banana 1 m
SenTix
®
52 120 12 Polyamide Fixed cable BNC+banana 1 m
SenTix
®
60 120 12 Glass S7 plug-in
connector
depending on S7
cable****
SenTix
®
61 120 12 Glass Fixed cable DIN* 1 m
SenTix
®
62 120 12 Glass Fixed cable BNC 1 m
SenTix
®
81 120 12 Glass Fixed cable DIN*+banana 1 m
SenTix
®
82 120 12 Glass Fixed cable BNC+banana 1 m
SenTix
®
91 170 12 Glass Fixed cable DIN*+banana 1 m
SenTix
®
92 170 12 Glass Fixed cable BNC+banana 1 m
SenTix
®
Mic 40/80** 12/5** Glass S7 plug-in
connector
depending on S7
cable****
SenTix
®
MIC-B 96*** 3 Glass Fixed cable BNC 1 m
SenTix
®
MIC-D 96*** 3 Glass Fixed cable DIN* 1 m
