9
GB
Product specifications
Typ A90 AR90 R90
Art. no. 0715 93 91 0715 93 970 0715 93 90
Operating pressure 6,5-7 bar 6,5-7 bar -
Emptying pressure 0.5-1 bar 0.5-1 bar 0.5-1 bar
Nominal tank capacity 90L 90L 90L
Maximum amount of waste oil 75L 75L 75L
Prechamber capacity 8L 8L -
Oil temperature during extraction 70 - 80°C 70 - 80°C -
Weight 36 kg 42.1 kg 34 kg
Maximum height 1,400 mm 1,880 mm 1,900 mm
Ambient temperature in use -10°C to max. +90°C
It is only possible to work safe-
ly with this product if you read
these operating instructions and
the safety instructions in their
entirety, fully understand the in-
structions and strictly follow the
information given.
qCheck the following parts for wear and function
prior to use: pipes, cocks, wheels, tank and ven-
turi unit (A90 and AR90 only).
qPull the small ring on the safety valve (next to
compressed air cock Q) to check the freedom
of movement (correct function) of the valve.
qStore the product in a place where it is protect-
ed from the weather.
qNever use on an uneven floor.
qDo not place any objects on the tank, as the
tank may then tip over due to imbalance!
qDo not place the tank upside down to drain the
waste oil!
qNever subject the tank to a source of heat.
qDo not perform any welding on the tank.
qProtect hands and face if you extract oils par-
ticularly at high temperatures.
qNever collect hydraulic fluid, corrosive or easily
inflammable liquids in the product.
qOnly use original Würth accessories.
For your safety
Correct use
These products are only suitable for use in garages.
The products are designed for collecting waste oil; the
oil can be extracted or collected. Any other usage is
improper and therefore not allowed (e.g. extracting /
collecting caustic or inflammable liquids, etc.).The tank
is not suitable for storing waste oil. The oil must there-
fore be regularly transferred to a suitable collecting
container.
Assembling products
Fig. 1
- Fit the handle (A) in the related holders and
then fix using the screws (B).
Fasten the pipe clip (C) and the tool tray (D).
Fig. 2
-
Connect the drain hose (E) to the hose union on
the cock and fasten using the hose clip supplied (F).
Close the cock (G).
Fig. 3 (A90 / AR90)
Fit the prechamber to the tank and ensure the seal is
fitted to the coupling. Fit the threaded ring and tighten
using a C-spanner.
