Würth ABH 18 COMPACT - Tool Specifications; Intended Use; Symbols

25
follow the instructions on risk reduction in this
manual.
˟ Electric shock after contact with hidden wires –
Hold the product only by insulated surfaces.
˟ Respiratory injury from dust created by operating
the product – Wear suitable protection depending
on type of dust.
7RRO6SHFLÀFDWLRQV
Cordless rotary
hammer
ABH 18
COMPACT
Article number 5701 403 00X
Voltage 18 V/DC
Chuck 1.5 - 13 mm
Suitable for SDS plus
No load speed 0-1400 min
-1
Maximum drilling capacity
in concrete
26 mm
Maximum drilling capacity
in wood
30 mm
Maximum drilling capacity
in metal
13 mm
Impact energy 2.5 J
Rated of percussion 0-4800 min
-1
Chuck neck diameter 43 mm
Weight (According to EPTA
procedure 01/2014)
3.75 kg (4.0 ah) -
3.76 kg (5.0 ah)
Weight - not incl. battery
pack
3.07 kg
Ambient operating
temperature for the tool and
battery pack
0 - 40°C
Ambient storage
temperature for the tool and
battery pack
0 - 27°C
Recommended ambient
charging temperature
5 - 40°C
Recommended battery type LI 18V/4 Ah BASIC
LI 18V/5 Ah BASIC
Recommended charger ALG 18/4 BASIC
ALG 18/6 FAST
Know Your Product
See page 3.
1. SDS chuck
2. Mode selector
3. Direction of rotation selector
4. Trigger switch
5. Handle, insulated gripping surface
6. Battery pack
7. Auxiliary handle, insulated gripping surface
8. Depth guide rod clamp
9. Depth gauge
10. Drill chuck
Intended Use
The drill can be used for drilling into various materials,
including wood, metal, and plastics using a drill bit
having a shank diameter of less than 13 mm. The
product can be used to drive and remove screws and
bolts using an appropriate bit.
For damage caused by usage other than intended, the
user is responsible.
Symbols
Read all safety warnings and all
instructions.
Warning
V
Volts
Direct current
No-load speed
