19
5HVLGXDO5LVNV
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual
risk factors. The operator should pay particular and
additional attention to these points in order to reduce
the risk of serious personal injury.
˟ Injury to hearing – Wear suitable ear protection
and limit exposure.
˟ Injury to sight – Wear protective eye shields or
goggles when using the product.
˟ Injury caused by vibration – Limit exposure and
follow the instructions on risk reduction in this
manual.
˟ Electric shock after contact with hidden wires –
Hold the product only by insulated surfaces.
˟ Respiratory injury from dust created by operating
the product – Wear suitable protection depending
on type of dust.
7RRO6SHFLÀFDWLRQV
12V drill driver compact ABS 12
COMPACT
Article number 5701 101 000
Voltage 12 V/DC
Chuck 0.8 - 10 mm
No load speed (drill mode)
Gear 1 0-400 min
-1
Gear 2 0-1500 min
-1
Clutch (positions) 16 + drill mode
Max. torque (hard/soft) 32/19 Nm
Maximum drilling capacity in
wood
20 mm
Maximum drilling capacity in
metal
10 mm
Weight (According to EPTA
procedure 01/2014)
1,2 kg (2,0 Ah) -
1,3 kg (3,0 Ah)
Weight - not incl. battery pack 1,0 kg
Ambient operating temperature
for the tool and battery pack
0 - 40°C
Ambient storage temperature
for the tool and battery pack
0 - 27°C
Recommended ambient
charging temperature
5 - 40°C
Recommended battery type LI 12V/3 Ah
BASIC
LI 12V/2 Ah
BASIC
Recommended charger ALG 12/3 BASIC
ALG 12/2 BASIC
Know Your Product
See page 3.
1. Keyless chuck
2. Torque adjustment ring
3. Gear selector
4. Direction of rotation selector
5. Trigger switch
6. Handle, insulated gripping surface
7. LED light
8. Battery pack
9. Belt clip
Protection feature
Protection Flashing times
of LED
Over current protection 4
Motor over temperature
protection
10
Low voltage protection 6
Abuse protection 12
