Tool Specifications
Line laser
Article number 0714 640 130
Laser type 635 nm
Laser class 2 M
Beam pulsation for operation with hand receiver up to a working range of 30 m
Levelling accuracy of line laser ±2 mm at 10 m
with hand receiver ±2 mm at 10 m/±6 mm at 30 m
(plus the sensitivity of the hand receiver)
Line accuracy
1)
±2 mm on a line length of 10 m
Length of horizontal lines approx. 25 m at a wall clearance
of 10 m
Power supply (operating life) 3 x 1.5 V-typ LR 6 (approx. 20 h)
Recommended operating temperature 0 °C up to 40 °C
2)
Protection class IP55
Weight (Tool + mounting device) 700 g
1)
Pay particular attention when working with the hand receiver at larger distances – the
value is added to the levelling accuracy. Maximum accuracy is achieved close to the cross
point.
2)
Operating temperatures above 50 °C can damage the laser diodes. (Caution when
keeping devices in the car in the summer season).
Working safely with this ma-
chine is possible only when the
operating and safety informa-
tion are read completely and
the instructions contained
therein are strictly followed.
Do not remove the label on the
side of the housing.
Laser radiation Laser class 2 M
(635 nm)
complying with EN 60 825-1
Do not look into the laser beam.
❏ Do not direct the laser beam at other
persons. Since the laser beam is of the
bundled type, check the beam path
over a relatively long distance and take
the necessary precautions.
❏ Use only original Würth parts and ac-
cessories.
2
GB
☞
For further notes on safety refer to the enclosed sheet
For Your Safety
