16
Symbols in this instruction
manual
Danger
For an immediate threat of danger
which causes serious injuries or death.
Warning
For a possibly dangerous situation
which may cause serious injuries or
death.
Caution
For a possibly dangerous situation which may cause
minor injuries or damage to property.
Device elements
Before using the device, the operator must familiar-
ise himself with all device features and the applica-
ble safety instructions.
Overview (fig. I)
1 Intake opening/cap with lter pad
2 Cover / intake slots for gas cartridge
3 Actuator
4 Battery's's charging state/maintenance indica-
tion
5 Battery unlocking button
6 Battery
7 Belt retaining bracket
8 Magazine lock
9 Magazine foot
10 Magazine
11 Follower
12 Release lever for follower
13 Sleeve
14 Exhaust gas opening
Proper use
This device is intended to be used for ring pins
(fasteners) into concrete, full block calcium silicate,
full bricks and steel using the original Würth system
parts.
Any other use than that described shall be deemed
to be improper use.
The user is liable for damage due to improper use.
Technical data
Prod. no. 0864 90 2
Firing power (max.) 1000/h
Pin length x pin - Ø (max.) 40 x 3.7 mm
Magazine capacity 42 pins / 22 pins
Dimensions (height x length
x width)
365 x 435 x 124 mm
Weight 3.7 kg
Gas cartridge item no. 864 900 500
Capacity 80 ml
Substance - Propylene
- But-1-ene
Hazard class 2.1 UN 1965
Max. ambient temperature 50 °C
Energy reserve
approx. 1100
ring processes
Mains adapter
Input voltage / current 100 - 240 V AC/
0.4 A
Output voltage / current 10 V /0.8 A
Charging period
- Discharging the battery 120 min
- rst start-up 24 h
Battery NiMH
Nominal voltage 6 V DC
Capacity 1.5 Ah
Ambient temperature 5 - 50 °C
Energy reserve with fully
charged battery
approx. 3000
ring processes
Method of functioning
The device has a combustion drive with explosive
gas mix. By ignition of the gas mix, the piston is actu-
ated and drives in the pin. Exhaust gas and noise
emissions, which may be hazardous to health, are
generated during the combustion process. Adhere to
the stipulated safety instructions.
