Product Description and Specifications
Read all safety warnings and all
instructions. Failure to follow the warnings
and instructions may result in electric shock,
fire and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.
Intended Use
The machine is intended for lengthways and crossways cut-
ting of wood with straight cutting lines as well as mitre cuts in
wood while resting firmly on the workpiece. With suitable saw
blades, thin-walled non-ferrous metals, e. g., profiles, light
uilding materials and plastic can also be sawed.
Working ferrous metals is not permitted.
For damage caused by usage other than intended, the user is
responsible.
Product Features
The numbering of the product features refers to the illustration
of the power tool on the graphics page.
1 On/Off switch
2 Lock-off button for On/Off switch
3 Thumbwheel for speed preselection
4 Auxiliary handle (insulated gripping surface)
5 Spindle lock button
6 Scale for mitre angle
7 Wing bolt for parallel guide
8 Clamping lever for bevel-angle preselection
9 Cutting mark, 0°
10 Cutting mark, 45°
11 Parallel guide
12 Retracting blade guard
13 Base plate
14 Lever for retracting blade guard
15 Chip ejector
16 Blade guard
17 Handle (insulated gripping surface)
18 Hex key
19 Clamping bolt with washer
20 Clamping flange
21 Saw blade*
22 Mounting flange
23 Saw spindle
24 Clamping lever for cutting-depth preselection
25 Cutting-depth scale
26 Wing bolt for bevel-angle preselection
27 Set of screw clamps*
28 Guide rail*
* The accessories illustrated or described are not
included as standard delivery.
Tool Specifications
Circular Saw HKS 65-E
POWER
Article number 5706 600 X
Rated power input W 1800
No-load speed min
-1
2300 – 5000
Rotational speed under load,
max. min
-1
1400 – 4000
Cutting depth, max.
– for 0° bevel angle
– for 45° bevel angle
mm
mm
65
48
Spindle lock
Speed preselection
Constant electronic control
Temperature Dependent Over-
load Protection
Reduced starting current
Base plate dimensions mm 203 x 327
Saw blade diameter, max. mm 190
Saw blade diameter, min. mm 184
Blade thickness, max. mm 1.7
Tooth thickness/setting, max. mm 2.6
Tooth thickness/setting, min. mm 1.8
Mounting bore mm 30
Weight according to
EPTA-Procedure 01/2003 kg 5.2
Protection class / II
The values given are valid for a nominal voltage [U] of
230 V. For different voltages and models for specific coun-
tries, these values can vary.
Only for power tools without reduced starting current: Start-
ing cycles generate brief voltage drops. Interference with
other equipment/machines may occur in case of unfavoura-
ble mains system conditions. Malfunctions are not to be
expected for system impedances below 0.36 ohm.
