Tool Specification
Pendulum Action Jigsaw STP 85
Part Number 702 635 X
Power input 580 W
Power output 350 W
Stroke rate at no load
500 – 3100 spm
Stroke 26 mm
Cutting ability
● in wood up to 85 mm
● in auminium up to 20 mm
● in stainless steel alloy/non-alloyed steel up to 10 mm/up to 3 mm
Bevel cuts (left/right) 0 – 45°
Weight (without accessories) 2.4 kg
Protection class
/II
For Your Safety
Working safely with this machine is
possible only when the operating
and safety information are read com-
pletely and the instructions contained
therein are strictly followed.
The machine must not be damp and
must also not be operated in damp
surroundings.
Before each use of the machine, check
the cable and plug. If damage is de-
tected, do not use the machine. Have
repairs performed only by a qualified
technician. Never open the machine
yourself.
For the mounting and replacing of the
saw blade 9, wear protective gloves.
❏ Wear protective goggles when working with ma-
terials which produce large amounts of chips.
❏ For work which produces dust that is detrimental to
health, a dust protection mask should be worn.
Materials containing asbestos should not be
worked.
❏ When working, never place a hand or fingers in
front of the saw blade.
❏ The improper use of accessories which are not in-
tended for this machine type increases the danger
of an accident and can lead to damage to the ma-
chine
❏ Connect machines that are used in the open via a
residual current circuit breaker with a triggering
current of 30 mA maximum. Use only extension
cables that are intended for outdoor use and are
protected against splash water.
❏ When working with the machine, always hold it
firmly with both hands and provide for a secure
stance.
❏ Always direct the cable to the rear away from the
machine.
❏ Apply the machine to the workpiece only when
switched on.
❏ The cutting path must be free of obstacles both
above and blow.
❏ When sawing, the complete surface of the base
plate 5 should securely rest on the material. For the
working of smaller or thin workpieces, use a stable
foundation or a saw table (accessory).
❏ When the cut is completed, switch off the machine
and then pull the saw blade out of the cut only after
it has come to a standstill (danger of kick-back).
❏ After switching off, do not brake the saw blade to
a stop by applying side pressure.
❏ Use only sharp, flawless saw blades. Replace im-
mediately cracked, bent or dull saw blades.
❏ Do not drill into housing or attach rivets in order to
mark the machine. The double insulation is then no
longer ensured. Use stickers.
❏ Use only original WÜRTH parts and accessories.
❏ For further notes on safety refer to enclosed
Sheet
GB
