Tool Specifications
Operating Controls
1 Motor
2 On/Off switch
3 Motor flange
4 Saw flange
5 Flange nut
6 Capacitor
7 Pump
8 Knob/legs
9 Clamping lever
10 Guiding roll
11 Guiding rail
12 Grip
13 PRCD protective switch*
14 Transportation lock
15 Knob/cutting depth
*Not all of the accessories illustrated or described
areincluded as standard delivery.
Intended Use
The sawing machine is only to be used for sawing
tiles, marble and ceramics in combination with wet-
diamond blades and a sufficient supply of water.
For damage caused by usage other then intended,
the user is responsible.
Before Use
Always use the correct supply voltage: The power
supply voltage must match the information quoted
on the tool identification plate.
On construction sites electrical appliances
should be connected to specially designed
power supplies.
Suitable are grounded main power supplies
equipped with an earthleak switch of max.
30 mA or separating transformers.
Non-grounded common household or simi-
lar power outlets are not suited as a power
source.
For water cooled sawing machines stricter safety
standards are applicable. Therefore, for extra safety
the machine must be connected according to one of
the following methods:
Main power supply equipped with earthleak switch*
30 mA.
--------------------- or ---------------------
Separating transformer*, only 1 machine may be
connected at any given time.
--------------------- or ---------------------
With an intermediate cable equipped with a PRCD
safety switch* of max. 30 mA.
* Not included as standard delivery.
Wet Tile Saw WAC 70 WAC 90 WAC 120
Article number 0701 407 2 0701 409 2 0701 401 2
Input power 1000 W 1500 W 1500 W
No-load speed
2800 min
-1
2800 min
-1
2800 min
-1
Blade diameter
Ø 200 mm Ø 250 mm Ø 250 mm
Hole
Ø 25.4 mm Ø 25.4 mm Ø 25.4 mm
Max. sawing height 35 mm 50 mm 50 mm
Max. sawing length 700 mm 900 mm 1200 mm
Saw table dim. (LxB) 575 x 360 mm 890 x 435 mm 1200 x 435 mm
Dimensions (LxBxH) 1050 x 400 x 400 mm 1230 x 450 x 650 mm 1540 x 450 x 600 mm
Weight 41 kg 52 kg 62 kg
Safety class
/I /I /I
