Tool Specifications
* For the following situations, using a target plate is recom-
mended already for closer working ranges:
- Poorly reflecting surfaces
- Reflecting surfaces (glass, metal, etc.)
- Bright ambient light, such as direct sun light
** Under unfavourable conditions, e.g., for temperature
alterations, for a poorly reflecting surface or bright ambi-
ent light, the error of measurement can be up to 3 mm.
For working ranges in excess of 30 m, the accuracy
declines by 0.1 mm/m.
Use as Intended
The device is intended for measuring distances and
inclinations, as well as for the calculation of areas
and volumes. The measured values determined by
the device may not be used to control or trigger
other equipment, machinery or systems. The device
is not suitable for operation in hazardous areas.
For damage caused by usage other then
intended, the user is responsible.
Display Symbols
1 Laser, switched on
2 Number of memory location
3 Measuring level (front/rear)
4 Illumination
5 Circumference
6 Mark-out function
7 Wall surface
8 Pythagoras I, II and III
9 Ceiling surface
10 Information
11 Main display
12 Unit of measure
13 Displays for intermediate values
14 Menu for Units, Reset, Tripod, Beep
ON/OFF
15 Continuous laser beam
16 Solid angle, inclination, horizontal dis-
tance via inclination
17 Area/volume
18 Timer
19 Battey status display
20 Memory function
21 Type plate
Keypad/Pushbuttons
22 On/Off switch, distance measurement,
tracking
23 Surface measurement/volume measure-
ment
24 Add button for calculations
25 Solid angle measurement
26 Change measuring level
Laser distance meter WDM 101
Order number 0714 640 710
Measuring range, direct 0.05 m – 80 m*
Measuring range,
with target plate 100 m
Inclination measurement ± 45°
Measuring accuracy, typ.
– Distance measurements ± 1.0 mm**
– Inclination measurements ± 0.3°
Smallest display unit 0.1 mm
Laser point Ø in
10/50/100 m 6/30/60 mm
Automatic shut-off
Laser/device 180 s/360 s
Memories of measured
values, amount 20
Automatic release/timer 5 s – 60 s
Batteries: Micro/LR03 2 x 1.5 V
Battery operating life 5 000 distance
measurements
Protection class IP 54
(IEC60529)
Storage temperature –25 ... +70 °C
Operating temperature –10 ... +50 °C
Weight, approx. 0.12 kg
The symbols on the device have the following meaning:
Laser irradiation
Do not look into the beam
Laser class 2
according to IEC 60825-1: 2007
Max. power output: <1mW
Wavelength: 620 – 690 nm
