X-lite X-1005 User Manual

18
X-1005
1.3 Place the PINLOCK
®
inner visor on the visor.
The silicone-sealed prole of the PINLOCK
®
inner visor must be in contact with
the inner surface of the visor.
1.4 Insert one side of the PINLOCK
®
inner visor onto one of the two visor pins and hold
it in position (Fig.8).
1.5 Widen the visor and fasten the other side of the PINLOCK
®
inner visor to the other
pin (Fig.9).
1.6 Release the visor.
1.7 Peel the protective lm off the PINLOCK
®
inner visor and check that its sili-
cone-sealed prole adheres to the whole visor.
1.8 Fit the visor on the helmet (see instructions above).
2 CHECKING AND ADJUSTING THE STRETCH
Check that the PINLOCK
®
inner visor has been correctly tted by opening and closing
the visor and ensuring that they do not move with respect to each other.
If the PINLOCK
®
inner visor is not tightly xed to the visor, simultaneously move both
external adjustment levers upwards to increase the stretch (Fig.7). This operation must
be carried out gradually. The maximum stretch is achieved when the pin adjustment
external levers are turned outwards.
WARNING
- Dust between the two visors may cause both surfaces to scratch.
- Scratched PINLOCK
®
visors and inner visors may cause reduced visibility and
must therefore be replaced.
- Regularly check the correct stretch of the PINLOCK
®
inner visor to prevent it from
moving and scratching both surfaces.
- If the helmet visor fogs up and/or condensation forms between the visors, check
that the PINLOCK
®
inner visor is both correctly tted and stretched.
- An excessive and early stretch of the PINLOCK
®
inner visor may result in exces-
sive adherence against the visor surface and/or permanent deformations with
subsequent inability to correctly perform any following adjustments.
- Intense sweating/breathing, use in particular weather conditions (low tempera-
tures, high humidity, sudden changes in temperature or heavy rain) or intense and
prolonged use may affect the performance of the PINLOCK
®
inner visor and cause
fogging or formation of condensation. In such cases, to restore the system ef-
ciency after using the helmet, remove the PINLOCK
®
inner visor from the helmet
visor and leave it to dry in warm and dry air. The same procedure must be applied
to the helmet, which should be left to dry to remove any humidity that may have
formed as a result of the conditions described above.
3 DISASSEMBLING THE PINLOCK
®
INNER VISOR
3.1 DISASSEMBLE THE VISOR EQUIPPED WITH the PINLOCK
®
inner visor (see in-
structions above).
3.2 Widen the visor and release the PINLOCK
®
inner visor from the pins (Fig.9).
3.3 Release the visor.
INSTRUCTIONS FOR USE

X-lite X-1005 Specifications

General

Standard	ECE 22.05
Retention System	Double D-Ring
Liner	Removable and Washable
Cheek Pads	Removable and Washable
Type	Full-face
Weight	1450g
Visor	Scratch Resistant
