Copyright © Vertical Leisure Ltd. 2017 | All rights reserved. Version: 1.02
5
When the A-FRAME is at its lowest height, it will require a
oor area of 4.4sqm (47 sq-ft) and when fully extended will
require an area of 8.9sqm (95 sq-ft).
The A-FRAME could be extended from its lowest height of
2450mm (96.45 Inches) to a height of 3480mm
(137.00 Inches) when fully expanded.
3480mm (11.42ft)
2450mm (8ft)
Height
Depth
Width
A-Frame Footprint/Build Dimensions
Height (mm) (Inches) Depth (mm) (Inches) Width (mm) (Inches) Sq. Ft Sq. M
2450
2530
2610
2755
2900
3045
3190
3335
3480
96.45
99.60
102.75
108.46
114.17
119.88
125.59
131.29
137.00
1955
2019
2083
2198
2314
2430
2545
2661
2777
76.96
79.48
82.00
86.53
91.10
95.66
100.19
104.76
109.33
88.38
91.25
94.17
99.37
104.21
109.84
115.07
120.31
125.55
2245
2318
2392
2524
2647
2790
2923
3056
3189
47
50
53
59
65
73
79
87
95
4.4
4.7
5
5.5
6.1
6.8
7.4
8.1
8.9
Measurement Key (To the top of the bar.)
Height - Measuring vertically from the floor to the top
of the bar.
Depth - Measuring between the triangle (Side Profile)
Width - Measuring between the front/back legs
(Front/Back Profile)
Fig 1.2 Fig 1.3
Fig 1.4
