REMOVING THE PACKAGING (Note: It is recommended to unpack with a helper)
The A-FRAME is packaged in a special way to protect all the parts from any damage during transit. First the A-Frame needs
to be lifted out of the box. It is very important to remove all the packaging prior to commencing installation. To remove
foam on the top bar, you must rst remove the Leg Connector. Push pin when removing - take out triangular section,
remove foam then replace. Make sure pin engages securely (please refer to gure: 1.6 ). Whilst unpacking the items, please
make sure you follow the Contents Diagram.
PINS
Push the pin in & pull out the Leg connectors at the same time. It is recommended that 2 people unpack the A-Frame and that care is taken to lift correctly.
Push pin in & pull out foam
Replace the Leg connectors making sure the pin pops out
Fig 1.6
Note: Some pins come pre-installed on the A-Frame
Lock
Pin
Lock Pin
Lock
Pin
Fig 1.7
To Next Page
