5
PRESSURE BOOSTER
3. APPLICATION EXAMPLES
Below are some practical examples of applications that can be implemented with the MULTIPLUS 2
control panel.
CLEAN WATER (LIFTING)
COMPONENTS KEY
22
Float switch for clean water
Level probe
Pressure switch
