STATE OF CHARGE INDICATORS
The state-of-charge (SOC) LED display has four (4) SOC indicators.
LED EXPLANATION
25% Red LED
The LED will ash when the battery is less than
25% charged. When the battery is 25%
charged, the LED will be solid.
50% Orange LED
The LED will ash when the battery is less
than 50% charged. When the battery is 50%
charged, the LED will be solid.
75% Yellow LED
The LED will ash when the battery is less than
75% charged. When the battery is 75%
charged, the LED will be solid.
100% Green LED
The LED will ash when the battery is less than
100% charged. When the battery is 100%
charged, the LED will be solid.
25%
50%
75%
100%
