2
1. Before Starting
Open the cable compartment cover behind the terminal (Figure 1) and find the
power input on the rear side of the terminal (Figure 2). Connect the plug from
the power adapter into the power input.
(Figure 1) (Figure 2)
■ Adapter spec:
LITEON PA-1061-71
Input: 100-240Vac 50/60Hz Output: 12V DC, 5A
■ Operating Temperature: 0 °C to 40 °C
■ RTC battery spec. : 3V, CR2032
Caution: Risk of explosion if the battery is replaced by an incorrect type.
Please dispose of used battery according to the instructions.
