XAC xCE-200WU-UH User Manual


4
(Figure 3-1) (Figure 3-2)
Optional wireless communication – E200WU terminal also supports a variety of
wireless communications to host machine including Wi-Fi, Bluetooth and
optional 3G communication.
For xCE-200WU-UH model with voice communication options (Figure 3):
6 - 1 x Landline port
7 - 1 x Telephone handset port – For Handset connector B
8 - 1 x Wireless SIM card slot
9 - 1 x Telephone base port - For Telephone base connector A (Figure 3-3)
Note:
 Ensure that the SIM card is inserted into SIM card socket as the
orientation of SIM card icon ( ) as in (Figure 3-2).
 A “click” sound can be heard when the SIM card is fully inserted
properly
 The figure below (Figure 3-4) shows connection between the phone and
E200WU device.

(Figure 3-3)
